Description
BOY 35 Electric
Advantages
• Parallel movement without double pump
• Compactness of a two-platen machine
• Highly dynamic injection unit
• Lubricant free tool installation area
• Improved synchronised movement during ejection
• Highest positioning accuracy
• Fitted with ALPHA® 6 control
• Floor space requirement of 2.29m2 (2871 x 797 x 1949mm)
Technical data
• Clamping force: 350 kN
• Max. daylight between platen: 500mm
• Distance between tie bars: 280 x 254 mm (h x v)
• Choice of 12, 14, 18, 22, 24, 28 or 32mm diameter plasticising units
• Max. shot volume: 76.5 cm3 (theoretical)
